Sliding Table Saw MJ320DK

Key Features

1. Electric Lifting & 0–45° Tiltable Main Saw
The main saw blade height is adjusted electrically for quick, effortless setup. The saw unit tilts smoothly from 0 to 45 degrees, allowing precise bevel cuts for joinery and decorative edges.

2. Dual Saw Blade Design for Chip‑Free Cutting
A pre‑scoring saw (120×20 mm) runs at 8500 r/min to score the material before the main saw cuts through. This eliminates splintering and chipping on both sides, delivering a flawless finish even on delicate laminated surfaces.

3. High‑Performance Touch Screen Control
The intuitive touch screen interface simplifies operation. Clear graphics and easy navigation allow operators to monitor settings and control the machine with minimal training.

4. European‑Style Parallel Fence
The rigid, angle‑adjustable fence ensures straight, repeatable cuts. An aluminum alloy middle scale—made from high‑strength extruded aluminum—provides excellent stability and precise positioning.

5. Precision High‑Chromium Steel Guide Rail
The sliding table runs on a high‑chromium steel guide rail. This material offers exceptional wear resistance, long‑term accuracy, and smooth, vibration‑free carriage movement.

6. Powerful & Reliable Motors
Equipped with a 5.5 kW main saw motor and a 0.75 kW scoring motor, the MJ320D delivers ample power for demanding materials. The two‑speed main spindle (4200 r/min) and high‑speed scoring spindle ensure optimal cutting performance.

Technical Specifications

Packing dimensions

• Machine body (iron pallet): 2200×1150×1220 mm

• Sliding table (poly‑wood box): 3300×480×300 mm

Why Choose the Hold MJ320DK?

The MJ320DK blends industrial‑grade construction with user‑friendly features. From the touch screen controller to the precision scoring system, every component is built to improve workflow, reduce material waste, and deliver professional results consistently. It is an ideal choice for furniture manufacturers, cabinet shops, and workshops that demand reliability and finish quality.
